High style embellishes high upgradeability with front, top, and rear ventilation, offering additional mounting options for upgrading cooling components in the future. If an optional RGB or ARGB fan is installed behind the front panel, the Cooler Master hexagon will also be illuminated on the front panel. A total of 6 fans can be mounted simultaneously, ensuring that even the most demanding builds can stay cool under heavy use.
Product Name | MasterBox MB600L V2 w/o ODD | |||
Product Number | MB600L2-KNNN-S00 (Steel) | |||
Exterior Color | Black | |||
Materials | Exterior | Steel, Plastic | ||
Left Side Panel | Steel | |||
Dimensions (L x W x H) | Incl. Protrusions | 405.5x204x455.3mm | ||
Excl. Protrusions | 400x204x455.3mm | |||
Volume (Liters Excl. Protrusions) | 37.15L | |||
Motherboard Support | Mini-ITX, Micro-ATX, ATX | |||
Expansion Slots | 7 | |||
Drive Bays | 5.25“ ODD | 0 | ||
2.5” / 3.5” HDD | 2 | |||
2.5” SSD | 2 | |||
I/O Panel | USB Ports | 2 x USB 3.2 Gen 1 Type A | ||
Audio In / Out | 1 x 3.5mm Headset Jack (Audio + Mic) | |||
Pre-installed Fan(s) | Top | N/A | ||
Front | N/A | |||
Rear | 1 x 120mm | |||
Fan Support | Top | 2 x 120mm, 2 x 140mm | ||
Front | 3 x 120mm, 2 x 140mm | |||
Rear | 1 x 120mm | |||
Radiator Support | Top | 120/240 (RAM height limit 32mm; install RAM first, then install radiator) | ||
Front | 120 / 140 / 240 / 280mm | |||
Rear | 120mm | |||
Clearances | CPU Cooler | 161mm | ||
Power Supply | 160mm | |||
Graphics Card | 350mm (w/o front fans & radiator) | |||
Cable Routing | Behind MB Tray | 18.5mm | ||
Dust Filters | Front, Top, Bottom | |||
Power Supply Support | Bottom Mount, ATX | |||
Warranty | 2 Years |
